10.1INCH CAPACITIVE TOUCH LCD (D) 1024X600, WAVESHARE 11280
- Zaloga NE
- Dobava 7 dni
- Znamka: WAVESHARE
- Id številka: 3519/
Key Parameters
| LCD TYPE | TFT |
|---|---|
| INTERFACE | RGB/LVDS |
| TOUCH CONTROLLER | FT5406 |
| TOUCH PANEL TYPE | Capacitive (5 multi-touch) |
| BACKLIGHT | LED |
| DISPLAY SIZE (MM) | 222.72(W)×125.28(H) |
| DOT PITCH (MM) | 0.2175(W)×0.2088(H) |
| ASPECT RATIO | 16 : 9 |
| RESOLUTION | 1024 × 3(RGB) x 600 (Pixel) |
| POWER CONSUMPTION | TBD |
| BACKLIGHT CURRENT | TBD |
| OPERATING TEMP. (℃) | 0 ~ +70 |
Specifikacije
Glavno
Processor
Broadcom BCM2837B0, Cortex-A53 64-bit SoC @ 1.4 GHz
Memory
512MB LPDDR2 SDRAM
Connectivity
2.4 GHz and 5 GHz IEE 802.11.b/g/n/ac wireless LAN, Bluetooth 4.2/BLE
Access
Extended 40-pin GPIO header
Video & sound:
1 × full size HDMI
Dimenzije
Dolžina
99 mm
Širina
207 mm
Višina
208 mm
